The I2M Platform (an acronym for Intelligence to Manufacturing) is an enterprise-grade Smart Manufacturing software for control, management and optimization of industrial plants.
Developed by a Brazilian high-tech company - DataBot Software Intelligence S/A - and based on almost 30 years of know-how in the industrial software field, it's framework is a structured, holistic approach to extract actionable insights from process data to achieve business value.
I2M Platform belongs to the new generation of Manufacturing Operation Management, integrating in the same tool Advanced Analytics with Artificial Intelligence and Machine Learning, Industrial IoT Layer, Cyber Security, MES (Manufacturing Execution System), Process Historian, KPI & OEE Management and Production Traceability & Tracking.
From data acquisition to intelligence layer feedback, it creates an end-to-end real-time loop with a cascade of algorithms that powers the predictive engine, addressing all the challenges involved in machine learning applied to manufacturing.
In order to provide cutting edge technology, high degree of Cyber Security and industrial standard Service Level Agreement (SLA), it is compliant with requirements and best practices established by the world’s leading organizations in Industry 4.0, Smart Manufacturing and Industrial IoT (e.g. Plattform Industrie 4.0, IIC, NIST, CNSA, ISA).
Operating since 2015, I2M Platform was global launched at Hannover Messe 2018 and has been used in a large spectrum of applications in continuous processes (plastics, steel) and discrete manufacturing (automotive industry). Currently, it manages about US$1 million in production per day.
Digitizes manufacturing within a structured dataset that tracks operations and describes the physical process over time, as well as its operational context.
Continuously monitor production with a suite of Unsupervised Machine Learning algorithms to detect abnormalities, autonomously applying analytical results.
Provides data-driven analytical results for decision support on the operational level (e.g. quality inspections, setpoint adjustments, maintenance planning).
INDUSTRIAL INTERNET
MACHINE LEARNING
ACTIONABLE INSIGHTS
Capture / generate, structure, communicate and persist all relevant data to describe the manufacturing process within that time frame.
Deploy the Supervised and Unsupervised Machine Learning algorithms that fit within that time frame, autonomously applying analytical results.
Provide data-driven actionable insights for decision support within that time frame, allowing stakeholders to optimize processes at all levels.
The Industrial Internet Consortium was founded in March 2014 to bring together the organizations and technologies necessary to accelerate the growth of the industrial internet by identifying, assembling, testing and promoting best practices.
Joint platform of German federal ministries and high-ranking representatives from industry, science and the trade unions focused on the development of operational solutions to maintain the country’s edge on the fourth Industrial Revolution.
The National Institute of Standards and Technologies (NIST) is dedicated to supporting U.S. competitiveness in areas of national importance from communications technology and cybersecurity to advanced manufacturing and disaster resilience.
The I2M Platform had its global launch at the Digital Factory sector of Hannover Messe 2018, the world’s leading trade fair for industrial technology – a global hotspot for the digital transformation of industry spearheaded by Germany.
“The foundation [of Industrie 4.0] is the availability of all relevant information in real time, by connecting all elements participating in the value chain, combined with the capability to deduce, from the data at any time, the optimal flow in the value chain.
By connecting humans, objects and systems, dynamic real-time optimized and self-organized inter-company value networks are created, which can be optimized according to different criteria – costs, reliability and resource consumption.”
Plattform Industrie 4.0
Models are developed to structure data so that computer-based systems can understand the logical interpretation of data sets (Machine-to-Machine Communications):
Edge Computing is a paradigm that leverages the advantages of Cloud Computing while mitigating it’s drawbacks. Rather than processing all the data from the shopfloor on-site or sending it all to the cloud for analysis, the I2M Edge Server dynamically distributes analysis along the computational resources available from endpoint to endpoint, improving connectivity:
Timestamps every discrete operation, generating and/or capturing all relevant traceability data and metadata, allowing products to be tracked over time.
This dataset includes all relevant discrete features and characteristics, either for the product itself or for each operation that compose its manufacturing process.
e.g. cycle time, weight, length, torque, angle
e.g. Quality Assurance, laboratory measurements
Analytical results from the Platform's Predictive Engine are associated with the corresponding TrackID, allowing the System to identify abnormal products and flag them as Outliers - as well as find others with similar patterns.
Logs automation alarms and continuously (~10 ms latency) tracks dozens of continuous process features to create a dataset that describes the physical process’ behavior over time.
e.g. temperature, pressure, voltage, pH, rpm, kg/h.
Data can be queried via the Historian with detailed charts and interactive graphs for data visualization. Statistical information regarding process curves (e.g. mean, sigma, min/max) are also available in both formats.
Events (e.g. setpoint adjustments, operator input, automation alarms) are also timestamped and persisted in the dataset, so that their effects on productive outcome and process behavior can be assessed.
Continuously computes operational and financial KPI scores for the manufacturing process. Data is used in the
Benchmark assets across the supply chain
Manufacturing Execution System (MES) module to manage production as well as input data and events.
Can be configured to autonomously consume data from third-party applications via the Platform’s API (e.g. SCADA, MES, LIMS, ERP, CRM).
Datastreams from the shopfloor are continuously (~10 ms latency) captured, structured, encrypted, communicated and persisted in the I2M Edge Server. This creates the Digital Thread, a synchronized, detailed information flow that describes the physical process as well as its context.
“Industrial analytics can be applied to machine-streaming data received from disparate sources to detect, abstract, filter and aggregate event-patterns, and then to correlate and model them to detect event relationships, such as causality, membership, and timing characteristics.
Identifying meaningful events and inferring patterns can suggest large and more complex correlations so that proper responses can be made to these events.
Industrial analytics can also be used to discover and communicate meaningful patterns in data and to predict outcomes.”
Industrial Internet Consortium
The I2M Platform uses its proprietary clusterization algorithms (a version of DBSCAN that has been optimized for datasets with a large number of features) to autonomously group unlabeled datasets of similar properties.
This analysis can be done along any number of dimensions (production features e.g. temperature, pressure, pH, voltage, position, time) to provide a comprehensive view of the manufacturing process.
Parameters for clusterization (i.e. Eps, MinPoints) are adjusted during the Data Science phase until clusters reach appropriate granularity. The platform characterizes them with statistical information for each feature (e.g. min, max, mean, sigma), as well as how each feature affected clustering results (e.g. EpsOff, Out, Delta).
There are several different algorithms for clusterizing datasets, and appropriateness is a product of both the datasets’ characteristics (e.g. shape, number of dimensions) as well as the system’s constraints (e.g. bandwidth, latency).
For its’ Smart Manufacturing module, the I2M Platform employs Density-Based Spatial Clustering of Applications with Noise (DBSCAN), a clusterization method that is significantly more resource-effective than its counterparts, as shown in the figure.
Once training is done, the I2M Platform starts using Deep Learning, a subset of Machine Learning that relies on algorithms that emulate the human brain: Artificial Neural Networks (ANN). This approach is only made possible due to the enormous amount of data accumulated by the platform, as well as the powerful computational capabilities of the I2M Cloud.
In this phase, rather than performing batch analytics to clusterize datasets, the platform uses the results from training to classify processes in real time, using Fuzzy Logic to attribute scores and determine what cluster (or combination of clusters) best represents each fraction of the process.
Unsupervised Learning classifies processes by their physical properties in order to group similar processes and distinguish them from those with different profiles. These clusters can then be correlated with production results either manually or automatically (e.g. quality inspection results linked to production traceability via TrackID, timestamp etc), classifying each one of them as desirable/undesirable.
This leads to the Supervised Machine Learning phase of the Data Science process, when the platform is taught which of the clusters are desirable and which are not, as well as the thresholds for these distinctions. This allows the platform’s AI to automatically enforce production policies that steers processes towards desired profiles, and away from undesired ones.
In order for the information drawn from Machine Learning to provide valuable insights to improve the process, the ML process itself has to adhere to the manufacturing context, so that models can aptly represent the real world conditions they represent.
DataBot and the client thus participate in a collaborative Data Science process to adjusts the parameters (e.g. EPS in Clustering as an approximation of acceptable error/deviation for each process feature) and the expected results of algorithms in order to ensure their applicability.
This approach creates Expert Algorithms, modeling the reasoning of experts in that given process, empowering them with automated conclusions based on a volume of data that would be impractical for them to analyze. It improves labor efficiency at all technical levels by empowering the workforce with intelligent insights rather than raw data.
Since the Edge Server maintains a real-time representation of all I2M Smart Assets (Digital Twin) and is able to communicate seamlessly with them (M2M), actions and changes of states in the Digital Twins can be instantly translated into equivalent operations in the physical asset.
As a result, all the computational tools available for the Digital Twin can be applied in the physical process in real time (~100 ms latency). This creates a layer of intelligence corresponding to the Control functional domain (IIC-IIRA) in Industrial Control Systems (ICS), on Level 1 (ISA-95.03) of the manufacturing process.
It deploys real-time (10~100 ms), AI-powered, latency-aware, closed-loop feedback controls that read data from sensors, apply rules and logic, and exercise control over the physical systems through actuators.
The I2M Platform uses its proprietary clusterization algorithms (a version of DBSCAN that has been optimized for datasets with a large number of features) to autonomously group unlabeled datasets of similar properties.
This analysis can be done along any number of dimensions (production features e.g. temperature, pressure, pH, voltage, position, time) to provide a comprehensive view of the manufacturing process.
Once training is done, the Platform’s Predictive Engine begins real-time Classification of the productive process based on the Classes established in the Clusterization stage.
Clusterization and Classification of discrete product features (e.g. cycle time, weight, length, torque, angle) for specific time windows or TrackIDs, as well as the operations that compose their productive process.
The Clusterization engine can uncover patterns such as how production mix affects average cycle times, so that production planning can be optimized.
On the shopfloor layer, the Classification engine can detect disturbances and abnormalities as Outliers (e.g. a disruption causing the takt time of a given operation to fluctuate abnormally).
Clusterization and Classification of continuous process features (e.g. temperature, pH, voltage, rpm, kg/h) for specific TrackIDs, operations, time frames or samples (~10 ms).
The Clusterization engine uncovers patterns and constraints across these continuous dimensions. Managers can, for instance, craft data-driven Standardized Work Instructions and Recipes with setpoints that take these relationships into account.
On the shopfloor layer, the Classification engine can detect undesirable productive patterns in real time, reacting autonomously (e.g. flag them for Quality Inspection).
Clusterization and Classification of Feature Variation (Mean/Sigma, an overall index of curve instability) for each continuous process feature.
In the Clusterization engine this can be correlated to previous classes to uncover patterns in how setpoints and operational conditions affect process stability - and how it in turn affects productive performance.
The Classification engine uses these results to detect abnormal and undesirable behavior patterns in real time, alerting stakeholders if it surpasses pre-established thresholds and ranges.
Clusterization and Classification of KPI scores (e.g. OEE, Net/Gross, MTBF, Starved/Blocked) for specific processes (e.g. a given TrackID’s production) or time frames (e.g. per shift).
The Clusterization engine provides an overall index of productive performance that can be correlated to previous classes to uncover patterns in how different process behavior profiles impact operational and financial outcome.
The Classification engine can detect fluctuations in performance in real time, alerting stakeholders if it declines or is insufficient to meet production goals.
I2M Platform’s cyber security is compliant with the Commercial National Security Algorithm Suite (CNSA Suite): cryptographic algorithms specified by the National Institute of Standards and Technology (NIST) and used by NSA’s Information Assurance Directorate (IAD) in solutions approved for protecting National Security Systems (NSS).
They include cryptographic algorithms for encryption, key exchange, digital signature, and hashing. Since 2015, NSA started preliminary plans for transitioning to quantum resistant algorithms, as follows:
| Algorithm | Function | Parameters |
| Advanced Encryption Standard (AES) | Symmetric block cipher used for information protection | Use 256 bit keys to protect up to TOP SECRET |
| ECDH Key Exchange | Asymmetric algorithm used for key establishment | Use Curve P-384 to protect up to TOP SECRET |
| Secure Hash Algorithm (SHA) | Algorithm used for computing a condensed representation of information | Use SHA-384 to protect up to TOP SECRET |
| RSA | Asymmetric algorithm used for key establishment | Minimum 3072-bit modulus to protect up to TOP SECRET |
| Asymmetric algorithm used for digital signatures | Minimum 3072 bit-modulus to protect up to TOP SECRET |
The I2M Platform is commercialized in the Software as a Service (SaaS) business model, with a monthly subscription rather than onerous upfront capital investments. This allows clients to achieve faster breakeven and improved Net Present Value, avoiding the pitfalls of Total Cost of Ownership associated with traditional models (e.g. software depreciation, hardware, network, database, human capital etc).
Additionally, this business model provides a series of technical advantages for clients:
The Platform can also be commercialized as MCOTS (Modified Commercial Off-The-Shelf), with customized dashboards, custom industrial IoT interfaces and specialized algorithms (subject to technical analysis and contractual addendum).
